Hinges for standard applications to suit cabinet doors up to 26mm thick.
The secrets inside! CLIP top BLUMOTION combines innovative technology, award-winning design and top quality motion within the smallest space, for soft-close BLUMOTION has been seamlessly integrated into the boss.
Included: 1 x 110° CLIP top BLUMOTION standard hinge. (Fixing method dependant on the chosen configuration)
Please note - All hinges require a suitable mounting plate.
Specifications
| Application |
Overlay/Dual/Inset |
| Brand |
BLUM |
| Depth Adjustment |
+3mm/ -2mm |
| Door Thickness |
16 - 26mm |
| Finish |
Nickel |
| Fixings Included |
No |
| Height Adjustment |
+/- 3mm |
| Integrated Soft Close |
Yes |
| Material |
Steel |
| Opening Angle |
110 Degrees |
| Requires |
CLIP Mounting Plate |
| Side Adjustment |
+/- 2mm |
| LDL Guarantee |
Lifetime |
| Hinge Arm Cover |
70.1503.BP |
| Hinge Boss Cover |
70T3504 |
| Works with Boss Spacer |
Yes |
| Closing Mechanism |
Sprung |
| Blumotion Device |
Integrated |
